Microsoft Teams – Change the Supported Meeting Mode on existing Skype Room Systems to Teams Mode by leveraging Intune Scripts

Microsoft Teams have been the highly adopted collaborative platform in few months time.It has been helping a ton worldwide and the new features that is been released every now and then makes us stay connected and expands the efficiency in every organization who have been using them.

By default Microsoft Certified Room systems are forward compatible with the new Skype for Business or Teams services while maintaining the same client user experience.Usually when any organization has only Skype then these meeting rooms will have the options only Skype enabled on them.

In this article we will be looking at how to enable the existing Skype room systems to have the capacity to host Teams Meetings in them.

Example screen of a Skype room system panel where we have the below options on the supported meeting mode while configuring them at the initial stage .

These devices are basically on KIOSK mode running on recommended versions of Windows 10 currently supported one being 1909 at the time of writing this blog.

Ideally when a Skype room system account have been migrated to Teams with all the prerequisites this mode on the meeting room devices needs to be changed to support Skype for Business and Microsoft Teams.

This can be done by using the local admin credentials of this Skype room system , logging into the system context and change the mode to support both Teams and Skype. In a real scenario for a small scale deployment for lesser than 10 rooms changing them manually from the local IT support is possible. But in a huge deployments where there are 100 plus systems deployed across the globe and making them change manually will be a uncomfortable experience.

This supported meeting mode on the Skype room systems is controlled via an XML file present on below location. This location is standard for all the meeting rooms running on KIOSK mode and have a file named skypesettings.xml


At startup these devices looks up for this XML file named SkypeSettings.xml on the above location. If it finds them it applies the configuration settings indicated by the XML file then deletes the XML file. The best thing is that we can mention only the changes that we require on the system on the XML file and it will update the delta changes and keep the other settings as same.

In order to enable Teams, Skype and have Teams as default client we can use the below XML


Now this XML can be easily pushed to all the Skype Room Systems via Intune Scripting Profile.

Below are the prerequisites before performing this action:

  1. The Skype Room Systems accounts must have thee Teams license assigned to them. This offers an easy migration path from Skype for Business to Teams by just enabling Teams on the device.
  2. The Skype Room Systems must have been registered on Microsoft Intune to target this intune scripting profile to them.

Login to Microsoft Intune- Navigate to Device Configuration – Create the Scripts as below. Ensure the script settings have all the default settings. Target them to the meeting room devices which requires this change.

Copy save them as ps1 and Use the below script on the script settings page.

$target = "C:\Users\Skype\AppData\Local\Packages\Microsoft.SkypeRoomSystem_8wekyb3d8bbwe\LocalState\SkypeSettings.xml"
$xml = "<SkypeSettings>
$xml | Out-File -FilePath $target -Force

After the next azure AD sync is completed on the targeted devices we can see the XML file to be successfully deployed on the below location.

Also we can see the overview of assigned and failed devices on the intune script profile. In our case it was successful since it deployed to targeted system without any issue.

Once the Skype room systems gets this XML and usually these systems reboots every night to check for the system updates install them as a maintenance window. During that time this XML will be updated since the device will be rebooted. Once this change has been applied to all the systems the Intune Script profile can be removed since it is a one time configuration change on the systems after the user accounts have the teams enabled.


Create storage container in Azure , store the XML file and make intune to pull the xml file from there. Keeping this option is beneficial just in case if we need to modify the XML file frequently for device settings.

Navigate to azure portal – Storage accounts – Select File shares

Create a new file share for the pushing the Teamsxml

Once it is shared we can use the appropriate url in the script.

Below script can be used for the same

$source = "storage file source url"
$target = "C:\Users\Skype\AppData\Local\Packages\Microsoft.SkypeRoomSystem_8wekyb3d8bbwe\LocalState\SkypeSettings.xml"
Invoke-Webrequest $source -Outfile $target
$xml | Out-File -FilePath $target -Force


Sathish Veerapandian

Microsoft Teams – Utilize Power BI to get more details on the Call Quality Dashboards

With Microsoft PowerBI we can gather more details from the call quality dashboards. As of now Microsoft have released 7 power BI desktop templates to accumulate more details on the Microsoft teams call quality dashboard.

PowerBI being a very potential platform for data gathering and analysis these new templates for Microsoft Teams have been more outstanding in terms of analyzing the Microsoft Teams data.

We will go through the overview of the reports and the configuration on this post.

Firstly the PowerBI Query Templates for Microsoft Teams needs to be downloaded.

We have below 7 templates report:

  1. CQD Helpdesk Report.pbit
  2. CQD Location Enhanced Report.pbit
  3. CQD Mobile Device Report.pbit
  4. CQD PSTN Direct Routing Report.pbit
  5. CQD Summary Report.pbit
  6. CQD Teams Utilization Report.pbit
  7. CQD User Feedback (Rate My Call) Report.pbit

These are customizable templates which can be used to analyze data. These above are PBIT file formats which can be used from PowerBI desktop which has the data source configured. If we need to open them directly from the powerbi portal they need to be renamed as pbix. If we are importing them from the powerbi desktop the following file MicrosoftCallQuality.pqx needs to be imported to the location [Documents]\Power BI Desktop\Custom Connectors folder.

From Desktop:

The initial requirement is that the PowerBI Desktop version must be installed and the data gateway already configured. The steps from Microsoft can be followed from here

Place the pqx file in below location. The below location will be automatically created once the desktop version is installed.

Set the data source:

Option 1: Use the Microsoft Call Quality (Beta)

In-order to set the data source open Power Bi desktop – Select get data – choose Microsoft Call Quality (Beta)

Once it has been connected we could see the below message as disclaimer since it is on beta roll-out at the time of writing this blog.

Next we will be having the below option which has all the details to build the query.

The moment when we click on load we will be presented with the below screen. Here we need to select the option direct query since we are getting the data directly from the Microsoft call quality dashboards.

Once connected we will have all the options to build our own custom reports by selecting all the required fields from the right , visualizations and filter. This option is very beneficial where we have our office network details uploaded on the call quality dashboard for detailed analysis and building our own custom dashboards. Here we have selected few fields for example and could see they are populated on the dashboard.

Option 2: Import the Teams PowerBI Templates report and publish them from the desktop.

The second option is to import the PowerBI Templates and publish them on the desktop. Inorder to import them navigate to file- import – select power bi template and import all the pbit format files. These templates have to be imported one by one.

Once imported we get all the details as per the template imported. We do further have an option to customize the reports. Click on publish to publish the reports directly to the workspace.

Choose destination the workspace to be published. In our case we have selected Microsoft Teams – CQD and thats the workspace created in PowerBI for Teams CQD.

Once its published we have the dashboards published in the workspace and ready to share.

When clicked on share we have the below options while sharing the report. Users will need powerbi pro license and CQD access role to access this report.

Importing from the PowerBI Web Portal:

Importing them from the web portal is very much easier. We need to click on the datasets – files and select get option since we need to import the downloaded files here to create the new content.

Select files and click on local file and choose the powerbi templates. Here we need to rename all the file formats to pbix since the portal will not recognize the pbit format version.

Once uploaded we can see the dashboards. The template dashboards have lot of information especially with user details breakdown which is very nice. The below example is from CQD Helpdesk Report. Here we have an option to search by users, conference or by date which is very convinient.

Further from the user activities tab it gives us more report as example below. The good thing is that we could see the device information on the end point.

Below example comes from CQD Teams Utilization Report. This gives more info on how the Teams is utilized by users in our organization.Few samples from the templates. The call count summary gives all the information in one view.

We get the location details as well in the over all call quality and gives the data for past 180 days.

User details are very impressive where we can see the app version, drivers and further we have filters on the right to customize the view.

Below example shows day details breakdown with further customization filters and fields to get data based on our requirement. The default report itself has lots of required data which is very great.

The mobile devices all quality also have lot of useful information with overall summary.

We get the mobile devices call quality with rendered devices, call quality trend and number of conference attended from the mobile.

The desktop version is very much convenient to create customization dashboards.Well there are more reports which are handy and available from these default templates which will be definitely useful and in the above examples we have gone through few of them. These reports can be customized easily and shared with less efforts and it gives a very good view with rich data experience.

Thanks & Regards

Sathish Veerapandian

Visualize Microsoft Teams Room Systems health components through Azure Monitor Workbooks

In the previous post we looked on how to configure Azure Monitor Alerts for Critical events that occurs on Microsoft Windows Devices which can be used for monitoring the Teams Room Systems. With Azure Log Analytics we could leverage few more components that will help us to visualize the status of the systems which are monitored through selected event logs and the performance counters.

Creating the Workbooks and making them visualize purely depends on the data that is been ingested on the corresponding log analytics workspace. So at the first stage its very important that we are sending all the required logs and counters which is mandatory for visualizing the metrics.

Firstly before creating the workbooks we need to devise a strategy on how to build a skeleton for the dashboard. This is very important since there are multiple options available and need to understand what important data that needs to be projected on the dashboard.

We will go through few examples of how to get started with creating the workbooks and visualizing the data.

We need to prepare the required Kusto Query Language which is required for visualizing the data. Below is a small example of one which will visualize the count of the perf counters by object name

| where TimeGenerated > ago(1h)
| summarize count() by ObjectName

To Render them as a pie chart we can use the below information

| where TimeGenerated > ago(1h)
| summarize count() by ObjectName
| render piechart

Example below will project only the affected systems which has failed windows updates, driver updates or any devices connected with room systems which are in a failed state.

search *
| where Type == "Event"
| where EventLog == "System"
| where EventLevelName == "Error"
| extend Status = parse_json(RenderedDescription).Description
| where RenderedDescription has "failed"
| project TimeGenerated, Computer , RenderedDescription

If we need to visualize them on a graphical pie chart we could do that as well by summarizing them to a string value which is available from the  parsed json file. Example it can be computer, Ip address , Device name or any data which is present on the raw event data.

search *
| where Type == "Event"
| where EventLevelName == "Error"
| extend Status = parse_json(RenderedDescription).Description
| project TimeGenerated, Computer,RenderedDescription
| where RenderedDescription has "failed"
| summarize Count=count() by tostring(Computer)
| render piechart

Above are just very few examples of rendering the data and making them visualize through kusto query language. There is a lot to explore and can project more data based on the logs that we are adding on the azure log analytics.

Now we have got some idea of how to create the visualization through the kusto query language there is an option to combine multiple queries and display them as a dashboard through Azure Workbooks. Earlier this option was enabled by view designer which is now replaced by enhanced version called Azure Workbooks.

There are multiple options which can be utilized and created dashboards with Azure Workbooks and below we will go through few of the options which will help us in creating our customized workbooks.

In order to get started with Workbook – Navigate to the log analytics workspace – Choose Workbooks

Click on New

We get the default summary of our query from our workspace with the below piechart view.

If we want to go with our own query we can remove the default query and select Add. Here in Add we have multiple options like below out of which Add Group seems to be very much interesting. With Add group we have the ability to add multiple queries and group them in a single workbook.

At the top of this group we have an option to add text which visualizes the workbook name and the details.

After selecting the group , now we have option to add query into the group.

When going into the advanced settings we have these options now to display the chart titles specific for this query.

In the style tab we do have some options to modify the HTML settings. By default this will fit in to one query per row and if we need to add three queries we need to adjust the width settings.
In below case I have added the width to 50 since trying to add 2 queries in a row. But its very important to note here that adding 3 columns and making them visible as a dashboard is fine only in Azure Dashboards. If we try to view them from Azure Workbooks 3 queries in a row is not sufficient to accommodate and we do not have option to modify the HTML editor at this moment.

Have added another query which will let us know the status of the systems which have reported the heartbeat in last 30 minutes through the perfom counters. In below case since I have only one system for demo it shows only 1 system.

The moment when we group them and display it shows the  view as below. By adding multiple queries based on our requirement it makes us easier to create the dashboards.

Further to this we have a lot of options in the visualization of the display based on the metric units. We can go through few of them.
For instance there are below options available to set visualization.

We can reduce the size of the visualization and we have 5 options.

Further in the chart settings we have option to define the column and the units.

In the series we have option to change the colour and add a custom display label.

To interpret further have chosen Graph which is very interesting.When entering into the graph settings we have the below options in the node format settings. This helps us to choose what fields that we can display on the view of these images in the dashboard.

We have furthermore tweaking information on the layout settings. The hive clusters are looking really nice like honeycomb in the visualization. And there is a category to group by field to select based on the available fields.

Now we have the category to choose based on the coloring type. Ideally this is very good to categorize based on healthy and unhealthy systems. This will group the healthy and unhealthy systems separately and finally display them as dashboards.

This blog gives an overview of how to visualize , group and create Azure Workbooks from Log Analytics WorkSpace. With Azure log analytics and Azure Workbooks it makes very much easier to monitor the modern Windows 10 & Linux devices. This facility can be very much leveraged easily in a direct cloud deployment model without the need of installing, configuring and maintaining a local monitoring solution.

Thanks & Regards

Sathish Veerapandian

Use Azure Log Analytics to notify critical events occurring on Microsoft Teams Room Systems

In the previous post we had an overview of how to create Azure Log Analytics and configure them to collect data from windows systems. Once the information is ingested in the workspace we currently have a choice to make alarms and notify the responsible team dependent on various signal logics which will be useful on monitoring these devices.

These alerts are scoped to each log analytics workspace. It will be a smart thought to isolate the services ,group them on singular workspace and create separate alerts for critical events happening on these monitored devices.

In order to create the alerts Navigate to alerts on the same workspace  – Click on New Alert Rule

Navigate to signal logic and choose the signal logic. There are multiple we need to see if any more interesting which suits our requirement can be added over here.

Now we have the required critical signals based on which the alert needs to be triggered. Usually the signal type will be from the collected events and the performance counters. In our scenario we could go with some default events from the list and also custom log search.

Device Restart Alert:

In our example for default one did choose the Choose the signal logic of heartbeat from the existing one – (Useful when the device turns off)

Select the required devices  – make operator threshold value 0 – aggregation 5 minutes & frequency of evaluation 1 minute (The frequency of aggregation and evaluation can be chosen based on the interval of how many times we want to check the heartbeat). In normal cases it is best recommended not to choose a smaller frequency time range for large volume of devices and probably for critical devices alone it can be selected on a smaller frequency time period.

Disk Threshold Alert:

Similarly like device restart we are having disk threshold alert by default which can be configured.

It notifies when it exceeds the configured space. Select the resource configured for Teams – Select the Condition – Select the computers – the object name whenever the % free space is greater than and choose the value 60 percent. The percentage can be altered based on our requirement.

Then we need to select the required object, instance , counter path and source system. In our case we have selected one performance counter % free space. This will alert us when the disk space crosses 60 percent of overall capacity.

Chosen aggregate period is 5 minutes and the frequency time is 1 minute for every evaluation. Again we can change the frequency of evaluation for this probably on two times in a day one on the earlier time and other one  on the evening.

Custom Alerts:

Custom Alerts are more intriguing. With custom alerts we must be able to avail most of our alerting mechanisms. We have to select the signal custom log search for the custom alerts.

Event  | where EventLog == "System" | where EventLevelName == "Error"
|where RenderedDescription != "*updatefailed*"
| where EventData != "DCOM"
| project TimeGenerated, Computer, RenderedDescription

Example used the above query to report only the events which has error messages apart from windows update and DCOM alerts . We can further filter on not contains operator and create custom query based on  our requirement.

When any error messages apart from the excluded events comes up in the targeted devices we will be alerted for the same.

Note there are multiple action types – Email/SMS/Push/Voice, ITSM and Webhook will be more convenient for us in this case on Skype room systems monitoring.

Email – We can send email Email/SMS/Push/Voice when the alert is triggered. This will be the most convenient and easiest part to start with. This will help us to collect all the used cases initially and see which ones are really helpful and the ones which is not helping us. Once we devise a strategy from the email alerts then probably we can go with the other alerting mechanisms.

ITSM – We can integrate with IT service desk management tool to create incidents when these alerts are triggered. Most of the IT service desk management tools are capable of API integration especially with Azure AD and must be easier to suffice this requirement.

Webhook- We can configure to send push notification to teams channels when these alerts are triggered. Probably a dedicated teams channel can be created for the first level of NOC monitoring team. Post that the webhook can be configured to trigger the critical events alert to the teams channel.

Now with the email alert – Created action group – Chosen action type email/SMS/Push/Voice

By default there are no action group created. So an action group must be created and targeted to NOC team email group.

Added the email address for notification. Well there are other options as well like sending SMS and Voice which could also be leveraged.

We do have an option to modify the email subject based on the alert details.

Finally we name the alert details , mark the severity , enable and create them.

We have the option to see all the  configured rules.

Once after configuration, we can see the statistical dashboards which provides us the summary of total alerts that have been triggered and their status.

We are receiving the email alerts when the disk space exceeds the configured level of 60 percentage.

Similarly when the device was turned off, the configured heartbeat alert triggered an email to the recipient.

Similar like this we can create multiple required alerts for critical events.

At this moment we have option to create alerts for every action type which can be targeted for all computers and they are charged individually on a very nominal price. So for multiple alerting types we need to create multiple action types. These alerts are purely based only on the collected logs which are present on the azure log analytics workspace. Just in case if we are trying to collect more details which are not present on the collected logs then we wouldn’t be able to create the alerts. The Azure logs Alerting mechanisms provide a great way to alert the critical events happening across the monitoring systems.

Thanks in Advance

Sathish Veerapandian

Microsoft Teams – Configure Azure Log Analytics for Monitoring Teams Room Systems

Microsoft Teams being the best collaborative solution there are lots of smart devices which are equipped with Microsoft teams for providing the smart meeting room systems with modern cameras, microphones and smart display screens. The best part on Teams application is it can function well in all ranges of devices with a support of basic hardware and running on a windows 10 operating system.

While there are numerous approaches to monitor the Microsoft Teams room systems this article we will go through the steps to monitor them through Azure Log Analytics.Like other applications Microsoft Teams App running on room devices will write all the events on the event logs.Through the Microsoft Monitoring agent in Microsoft Teams it allows these events to be collected in Azure log Analytics.


  1. Subscription with Azure to configure log analytics workspace.
  2. Teams meeting room system with internet connectivity. There are other methods to collect the logs without internet through  Log Analytics gateway in this approach we are going with direct agent method.
  3. The Teams devices must be running on a windows operating system on all meeting rooms on a KIOSK mode or probably on a full operating system mode based on the requirements.

Create Azure Log Analytics and integrate with Microsoft windows agent.

Log into log analytics workspace

Create new log analytics workspaces. We can use the existing workspace as well and it purely depends on the requirement.

Choose the  required subscription

Once the Log analytics workspace is created , we need to go ahead and download the windows agent. The agent can be downloaded by navigating to Log Analytics Workspaces – Workspace name – Advanced Settings – Connected sources – Windows servers – Download the windows agent.

Install the MMA agent on Teams Skype room system device –

Select only the option connect the agent to azure log analytics (OMS) because in our case we are not monitoring them via a local monitoring agent SCOM.

Enter the workspace ID and the key from the log analytics workspace and select Azure Commercial. If the network is going through proxy then click advanced and provide the proxy configuration. If the device is not having connection to the internet then the agent cannot send the logs to log analytics workspace.

Once installed we can see the Microsoft Monitoring Agent present on the control panel.

Once opened can see the Azure log analytics (OMS) and see the status to be successful.

On editing the workspace we can see the workspace ID and the Workspace Key.

Usually it takes a while to collect the logs to Azure Monitoring agent.

Configure the required logs to monitor:

Once the log analytics workspace is being collected we need to configure the data sources so that the log analytics workspace can start collecting the  required data for monitoring the Teams Room Systems.

In our case for monitoring the teams device, we need to collect teams app logs and few hardware related events. We will look into configuring them now.

Note: We have to be very choosy here on collecting only the required events, since dumping logs to azure log analytics involves cost in it and best recommended to choose only the required events.

In order to collect the logs navigate to advanced settings – Choose data sources – select windows event logs

The key primary log that needs to be collected is Skype Room System (we have to type them completely and click add as this log entry will not autocomplete)

There are few more log events that can be added, but added these logs which might be helping on monitoring the Teams room devices.

Having added the windows event logs, we can navigate to windows performance counters and there are few events which can be added and useful for us to notify when the devices are having any of the below issues on them.

Querying the logs:

Once we have configured the required log sources it’s the time for us to run some queries and see if the logs are been collected. The azure log analytics workspace works well with Kusto Query Language and SQL Query Language.

There are default queries like Computers availability today , list heartbeats and unavailable computers.

Once selecting on the default templates list heart beats and can click on run the below results is obtained.

To see only the Application Event logs we can run the below query

search * | where Type == "Event" | where EventLog == "Application"

To see only the Errors generated in the application event logs

search * | where Type == "Event" | where EventLog == "Application" | where EventLevelName == "Error"

To drill down more and look into the perfmon logs ran the below query to check the system up time.

Perf| where CounterName == "System Up Time"|summarize avg(CounterValue) by bin(TimeGenerated, 1h)

There are lot of queries which can be built from these collected events. Having collected these events , we can configure them to display as dashboards and collect alerting mechanisms for the critical events. In the next post we will have a look at how to configure the alerting systems for critical events that’s happening on the meeting room devices.

Thanks & Regards

Sathish Veerapandian

Microsoft Teams – Deploy Information barrier policies for your organization.

A year ago Microsoft released the information barrier policies as another security enhancement feature in Microsoft Teams. With this new component it helps the organization to enforce policies which prevents the communication between specific group of people. This is primarily helpful and beneficial for the organizations who are into manufacturing and production units where they would need to adhere certain industry standards and guidelines usually to avoid conflicts of interest.

Before we actually move into deploying the information barrier policies segmentation of the users needs to be done.Ideally the business requirement which falls into compliance category to prevent communications between groups of users in Microsoft Teams. For example a person from Marketing Team cannot make a call,send instant messages or share his desktop to Research department. It can be vice versa or its is only one direction. All the sets of users needs to be identified because this contributes to the number of the segments that we are going to create for this policy to prevent the communication between them.

There are three key elements involved in creating the information barrier policy:

1) Segment the users in your organization.
2) Define Information barrier policies.
3) Apply the information barrier policies.

Below prerequisite needs to be met for creating the information barrier policies:

1) Users must have any one of the following license assigned – Microsoft 365 E5,Office 365 E5,Office 365 Advanced Compliance or Microsoft 365 E5 Information Protection and Compliance.

2) Enable scoped directory search for Microsoft Teams

Scoped directory search can be easily enabled from the teams admin center with the below toggle switch.

3) Turn on the Auditing on the audit log search page in Security and Compliance center. This is required for troubleshooting Information barriers policies. If we do not see them turned on then it is already enabled.

4) No address book policy should be enabled if we need this feature. Because Information barriers are based on address book policies and if we have them it might create a conflict and start working based on the configured address book policy.

5) Grant Admin consent for information barriers in Microsoft Teams.

$sp=Get-AzureRmADServicePrincipal -ServicePrincipalName $appId
if ($sp -eq $null) { New-AzureRmADServicePrincipal -ApplicationId $appId }
Start-Process  "$appId"

Once we run the above command global admin with the required privilege needs to grant admin consent to the information barrier processor app. This helps information barriers from removing persons from chat sessions where they are not supposed to be in them.

6) Ensure that the required data user attributes are populated in the user attribute fields which is required to identify and apply the information barrier policy.

In our example we’ve chosen 2 ideal candidates and populated the department attribute value which will be used for segmentation.

Now we need to segment users which means “Block” policies prevent sales group from communicating with research group.

In order to accomplish this task we need to connect to office365 security and compliance powershell module

In our example we can take two groups marketing and research where they both shouldn’t communicate with each other.

New-OrganizationSegment -Name "Marketing" -UserGroupFilter "Department -eq 'marketing'"

The above example creates a segment of users who are only from marketing department.

In our case we need to create one more segment of users where they belong to research team

New-OrganizationSegment -Name "research" -UserGroupFilter "Department -eq 'research'"

Now we have created the segment the information barrier policies needs to be created. Now we have to keep few things very clear in mind while applying the information barrier policies. For instance two policies cannot be applied to one segment of users. It is always advisable to make this information barrier policy to inactive status once they are created. Later we can edit this and apply for all users.

When we block communication between two segments in our case marketing and research we need to define two policies. A very important point to note is that each policy blocks communication one way only.

New-InformationBarrierPolicy -Name "Marketing-Research" -AssignedSegment "Research" -SegmentsBlocked "Marketing" -State Inactive

Now we need to create another policy to block the marketing department to communicate with research.

Activate the information barrier policy

Set-InformationBarrierPolicy -Identity GUID -State Active

We can verify the information barrier policies that we have created to ensure they have the correct values as per our requirement.

Now we need to start the information barrier policies with the below command


As per the information we’ve received in the above command we need to wait for a while until the deployment gets completed in our tenant and will be successful once the status becomes completed.

Testing the information barrier policy to applied recipient.

Now logged in as Vijay Raghavan user from Marketing Team while attempting to search for Clen Richard from Research he gets an empty result.

However he is able to lookup for other users.

The users who are applied in this policy will not be able to add the blocked users in any of their teams as well.

The same thing happens for the other user Clen Richard on attempting to talk to the user from Marketing Team.

Subsequently the information barriers adds a great value to any organization to uphold the communication compliance with few easy steps from the office 365 security ad compliance center and consistently utilize Microsoft Teams.As of now information barriers apply to Microsoft Teams chats and channels only.

Microsoft Teams – Utilize the AzureADMSGroupLifecyclePolicy command to manage the teams group life cycle

With the Azure active directory powershell commandlets, we could control the lifecycle of office365 groups.Ideally when any office365 group is created for an action of creating a team in the backend it creates the azure ad group.With the Azure commandlets we have options to control the lifecycle of the office365 groups automatically.

Let’s say we ‘ve created Team for a partner project which completes in 1 year time period, we have got an option to expire this team in 1 year time during the team creation.This keeps the access reviews of the Microsoft Teams intact and ensures that only required persons have access to the company corporate data.

The default setting is unlimited days as it should be for most of the scenarios.

Firstly we need to connect to azuread module from the powershell. Since we do not have any group life cycle policy the value remains empty.

Below example creates a a new groupLifecyclePolicy. This policy can be applied to targeted set of office 365 groups.

New-AzureADMSGroupLifecyclePolicy -GroupLifetimeInDays 99 -ManagedGroupTypes "groupid" -AlternateNotificationEmails ""

The managed group type parameter provides us the option to choose how we can manage the groups in our environment. Keeping the value “None” will create the policy but will not be applied to any groups. Specifying them “All” will apply this policy to all Office 365 groups. “Selected” will provide us the option to choose specific Office 365 groups.

To test this we can try to apply this policy to single group Teams-Partners. This group was created as an action of creating a team in Microsoft Teams.

In order to apply to a group we have to run the below command by specifying the group ID.

Get-AzureADMSGroupLifecyclePolicy -Id "admsgroupid" | Add-AzureADMSLifecyclePolicyGroup -GroupId "ID"

If we need to apply this to a group of ID’s which were reviewed and require to set expiry we can apply them from a input csv.

$policy = "mentionthepolicyID"
#keep the groupid as the input value in the csv
$365group = import-csv ".\365group.csv"
Foreach ($group in $groups) {
Add-AzureADMSLifecyclePolicyGroup -Id $policy -groupId $group.objectId}

We can run this on a periodic interval after performing access review on the Office 365 groups.There is also an option to notify the group owner on a particular period of time to review if they still require this group to be in the system. Keeping this option will remind the owner of the group who created the team to decide if they require to provide access to the users and external parties if the guest users are added to them.

We can then verify if it is applied for a group by using the commandlet Get-AzureADMSLifeCyclePolicyGroup by specifying the group id. This will return the output of to which AzureADMSgroup it have been assigned. We do have an option to extend the grouplifetime to our desired interval.

There are few organizations where the Office 365 group and teams group creation is provided as self service to users to increase the Office 365 adoption rate.In those cases the admin can review the groups created once in a month and apply the expiration policy for them.

This option will be better for the admins to create the expiry of the groups as per the company security policy.If we are doing a periodic review we can also use a input CSV for the selected groups and can apply the policy to these selected groups.

Microsoft Teams – Notify security administrator when a new team is created by the end users

Microsoft Teams is being used as a most preferred method of communication platform by many organizations. By default in office 365 the group creation is enabled for end users which will allow them to create public and private groups. Few organizations are having the group creation disabled on the organization level for larger scale companies and have users request for creating the teams using a request form which will run through a automation process in the background with help of azure automation accounts ,Microsoft flow or few other mechanisms.

But few organizations are really interested in allowing the users to create the Office 365 groups once their workloads are migrated to office 365. This is primarily to increase the adoption rate of Office 365 workloads Microsoft Teams and SharePoint online.

We have more options available in Office 365 cloud app security. By leveraging these options we can better secure the Office 365 suite of products which in turn controls the Data loss prevention, security compliance, information governance and threat management for the entire organization.

Through Cloud App Security –

Navigate to Cloud App Security –

Select and create Activity Policy

Do not choose any policy templates – select policy severity – category as per classification – Have selected compliance in below example.

Choose the acton single activity – activity type – equals – Team Created.

There is another alternative to create the policy as below by choosing the teams app. Going with this approach provide us more options like to get notified when teamsettingchanged,cut/copy item. adding a channel, changing a channel settings and when a team is deleted. There are lot of other actions which can be added based on our requirement.

Choose the severity and specify the email notification alert with no action.

The security administrators responsible for viewing this new group creation alerts can be added over here.

Further governance actions can be specified. We have an option to notify user and cc additional user with custom message.

The custom message can be added over here. There is an option to add a hyperlink as well.

When a new team is created by the end user the specified email address is notified.

We get more information on the cloud app security alerts.

We can use cloud app security for other activities in office 365 applications as well to notify the security administrators or the SOC team, so that they will be able to monitor the events which are categorized as non-compliance in Office 365 organization according to their security guidelines.

Thanks & Regards

Sathish Veerapandian

Review and Remove inactive guest users from Microsoft Teams through Identity Governance – Access reviews

When an office 365 group is created, we have options to collaborate with public partner accounts .As a result of this People outside organization can see and have access to office365 public groups contents when they are been invited as guests.

When we have allowed the end users to create the office 365 groups and invite the external partners to collaborate,over a period of time the groups left unattended without the access reviews. There is a high possibility of an user having access to the sensitive documents which they don’t need them anymore.

In order to alleviate these security issues , we can influence the Microsoft Azure Identity Governance – Access reviews

With the access reviews created for office365 groups , we can let the group owners review their office 365 public group guests present on them and take necessary action based on the requirement.

In order to create access review navigate to azure portal – Identity Governance – Access reviews – Click on access review – Select New access review.

Now we can create them with name ,description , start date and frequency of how often the access reviews needs to take place for the office365 groups.

We can set the number of times, end date and the scope to guest users only. And target the external groups which have the guest users added. Probably this part needs to be reviewed periodically and add the new groups in this list.

Furthermore we have the options to customize the reviewers who will be the reviewers of this access review task.

Upon completion we have the action to choose – Remove,Approve or take recommendations.

Finally we have few options which is present in the advanced settings. Once the customization is done as per the requirement we can start the review.

Once the schedule is triggered as per the configuration the reviewers get an email with the timeline.

Once clicked on review the user gets the guest user details and the options to take action based on the business requirement.

The reviewer gets an option to type the comment and take the necessarily action.

We have the review results section where we have an option to download the access review tasks and save them for ISO audit compliance which will help during the ISO Audit Evaluation cycles.

This is usual in most of the organizations when the guest accounts are provided access to the business sensitive content. Ultimately its the group owner’s responsibility to periodically review them and take necessary actions.

There is lot more to get benefited with Identity Governance access reviews. The above method will help us in evaluating and having right access only to the required individuals in Office 365 Groups.


Sathish Veerapandian

Microsoft Teams – Enable data loss prevention,ATP safe attachments,retention of files and conversations

Security is considered one of the success factor for any implementations.With Office 365 security and compliance there are lot of options to enforce the security across Office 365 suite of products.We can enforce DLP on Microsoft Teams based on our requirement. ATP can be turned on for all file upload activities in Microsoft Teams. The best part is that now we do have option to enable retention as lesser as 1 day in Microsoft teams channel messages and chats.

Microsoft Data Loss Prevention have been protecting sensitive information across all Office365 platforms. The easiest part is that we already have more custom built-in templates which will be easier for us to create,test,evaluate the results and finally create one for the production.

DLP Policy in Teams:

To create a dedicated DLP policy for Teams navigate to security and compliance center – Create a new policy.

In our example we are creating a new policy which will block the sharing of PAN card number via teams channels and chats.

In locations tab ensure that we are selecting teams chat and channel messages if the location is going to be only teams. If we need on all locations then we can keep them all enabled.

Under policy settings we do have lot of prebuilt templates which is super simple for us to just select and apply. In our case we are just selecting Block Indian PAN CARD number not to be shared via teams channels and chat messages.

Now we’ve created the teams data loss prevention policies and its time for us to test the created policy.

Have just logged into my test account and attempted to send a PAN Card to my account. The moment the PAN card is shared it is immediately blocked from the DLP policy.

And from the recipient end received the following message and the message is not delivered since it matches our DLP policy.

With the DLP policy we will be able to secure our sensitive information in Teams Channels and chat conversations.

Enable safe attachments on Teams Channels and chats :

Enabling ATP on Teams is pretty straight forward.

We need to navigate to protection security center – threat management – policy – select safe attachments.

All we need to do is to just select turn on ATP for SharePoint, One Drive and Microsoft Teams.

Once the policy is enabled and when somebody attempts to share an infected file the file is blocked but still present in the library, however no one will have the ability to open them from their side.

Files are scanned asynchronously, through a process that uses sharing and guest activity events along with smart heuristics and threat signals to identify malicious files.

To review the quarantined files we can go to threat management – review – select view quarantined files

Enable Retention in Microsoft Teams channels and chat conversations:

By default teams conversations and files are retained forever. With the new retention policy introduced in Microsoft teams channels and chats now admins have the option to customize the retention and delete the data forever if it is considered as liability according to the company retention policy.

In-order to create retention policies navigate to security center – select information governance – select retention – click create

Have created once dedicated policy for Teams Retention.

Now we choose the retention settings as per our requirement. The good part is that we do have the option now to retain the content lesser to even 1 day time.

Now we need to create a new retention policy for Microsoft Teams. If we try to edit the old retention policy there wouldn’t be an option to include Team Channel Messages and Chats , since these locations were on-boarded recently in the retention policy scopes.

Once selected based on the retention period all the Teams channel messages and chats are retained.

If end users delete their Teams messages, these messages are still preserved and available for search through eDiscovery for particular years based on the retention period set in the policy.

In order to recover a deleted file from channels – navigate to the channels – files tab – select open in sharepoint

Now after clicking on open in SharePoint – navigate to recycle bin and we could see the deleted file present.

We do have the same restore option like what we see in SharePoint sites.

With all the new security enhancement and retention channels enabled in Microsoft Teams it makes more convenient better communication platform for all users in the enterprise environment.

<span>%d</span> bloggers like this:
